Spring Roller Blind
Spring Roller Blind is a chain-free manual roller blind that is raised or lowered from the bottom rail. Its spring-assisted mechanism keeps daily operation simple while maintaining a clean and uncluttered window appearance.
- Control
- Bottom-Rail Pull
- Power
- None
- Operation
- Manual Spring-Assisted
- Warranty
- 5-Year Component Warranty
System Overview
Simple interaction. Clean architectural control.
The fabric panel rolls around a tube and is assisted by an internal spring mechanism. Instead of an exposed chain, the visitor operates the blind directly through the bottom rail, raising, lowering, and holding the panel at the preferred height.
The result is a clean cordless profile suited to interiors where everyday control should remain quiet, direct, and visually restrained.
Key System Benefits
- Cordless operation
- Direct interaction
- Clean integration
- No electrical power
- Compact Roller Blind format
Common Applications
- Bedrooms and rest spaces→
- Living rooms and residential interiors→
- Villa interiors→
- Hotel guest rooms→
- Office interiors→
- Compact glazed openings→
Product Overview
Spring Roller Blind
Flexi Stop (Spring)
Spring Roller Blind
A chain-free manual roller blind operated directly from the bottom rail. An internal spring mechanism assists raising and lowering while keeping the window line clean and uncluttered.
Specifications
System Specifications
Verified Flexi Stop (Spring) limits for interior roller blind applications.
Max Width
200 cm
Widest verified opening
Max Height
280 cm
Tallest verified opening
Min Width
65 cm
Narrower openings need confirmation
Max Area
4.8 m²
Recommended maximum blind area
Max Load
3 kg
Total stated load limit
Operation & Control
How the Spring Roller Blind is operated day to day.
- Control
- Bottom-rail pull
- Operation
- Manual spring-assisted
- Power
- None required
- Warranty
- 5-year component warranty
Project Pricing
Starting price for a complete blind configuration.
Starting from
Rp 633.000 / m²
Complete blind with selected Dimout Deluxe fabric
- Listed price includes PPN
- Minimum complete-set billing is 1 m²
- Width or height below 1 meter is billed as 1 meter for the complete-set minimum rule
- Final price depends on fabric collection, opening size, and selected components
Compatible Fabrics
Verified interior fabric groups for Spring Roller Blind specification.
6 verified groups
- Dimout Deluxe
- Semi Blackout / Blackout Deluxe
- Blackout Superior Series
- Blackout Premium Series
- Solar Screen
- Silver Backing
Standard Package
What is included
Complete blind with fabric and Spring mechanism
- Selected fabric panel
- Spring-assisted roller mechanism
- Standard hardware for the confirmed configuration
A complete Spring Roller Blind combines the selected fabric with the spring-assisted roller mechanism and the standard hardware required for the confirmed configuration. Final tube, bottom rail, bracket, and component selection depends on blind dimensions and fabric specification.
Installation is quoted separately according to project location, mounting conditions, and order volume.
Accessories
No separate accessories
This system is supplied as a complete package.
Additional components are not sold separately for this product.
Example Projects
Installed in real openings.
Selected Spring Roller Blind installations from the SharpPoint archive.
Coming Soon
Installation photography will be added to the archive.
Coming Soon
Installation photography will be added to the archive.
Coming Soon
Installation photography will be added to the archive.
Coming Soon
Installation photography will be added to the archive.
Other Roller Blind Systems
Explore other roller blind systems
Roller Blinds | Manual Systems
Ready to specify your Spring Roller Blind?
From Rp 633.000 /m²
Share your opening dimensions, preferred fabric, privacy level, and mounting conditions. Our team will help confirm the right Spring Roller Blind configuration for your project.
